Elliptical Tank Heads: A Cost-Effective Solution for Medium-Pressure Tanks

2:1 elliptical tank heads are an ideal choice for medium-pressure tanks due to their efficient design and reduced metal thickness requirements. These heads offer a cost-effective alternative while maintaining structural integrity.

Specifications

• 2:1 Elliptical Heads

• 120″ OD x 1-1/8″ Minimum Thickness – SA516-70N

• 120″ OD x 3/8″ Minimum Thickness – SA516-70N

Unlike tank heads with a fixed dish or knuckle radius, 2:1 elliptical heads are shaped according to a specific contour. The dish radius is approximately 90% of the internal diameter, while the depth of the head is one-quarter of the vessel’s internal diameter. These features make elliptical heads widely used in pressure vessel applications.

Haipei Industry provides high-speed manufacturing solutions for cold-formed tank heads, segmented umbrella domes, and spherical shroud gores to meet various industry needs.

Key Features of 2:1 Elliptical Tank Heads

• Economical for medium-pressure applications due to reduced material usage

• Also referred to as ellipsoidal heads, consisting of:

• A rotating ellipsoidal dome

• A cylindrical straight section

• Type: Cap

• Shape: Semi-elliptical

• Materials: Carbon steel, stainless steel, duplex steel

• Custom Manufacturing: Precision punching available per client specifications

• Compliance: Designed to meet ASME standards for carbon steel dished ends in cylindrical pressure vessels

Industry Applications

Our tank heads are widely used in:

• Pharmaceutical industry

• Chemical processing

• Biotech applications

• Cryogenic storage

• Power generation

• Heat exchangers

• Water treatment and desalination

• Oil and gas exploration

Dimensions & Material Options

• Diameter Range: 89mm to 13,000mm

• Thickness: 2mm to 400mm

• Reduction Ratio: ~10%

• Material Choices: Carbon steel, stainless steel, duplex steel

Overall Head Height Calculation

Total Height = Internal Diameter + Straight Flange + Material Thickness

Available Tank Heads

We maintain a large inventory of 2:1 stainless steel semi-elliptical tank heads, with:

• 12,600+ heads in stock

• 3,400+ in active production

• Sizes ranging from 12″ to 48″

Additional Options

• ASME 2:1 Semi-Elliptical Tank Heads

• Diameter: 6-5/8″ to 192″

• Thickness: 3/16″ to 3″

• ASME Flanged & Dished Tank Heads

• Diameter: 14″ to 250″

Specialized Fabrication

We specialize in the production of large-diameter, multi-piece segmental tank heads, ensuring efficiency and high-quality results in various industrial applications.

Company information

Haipei industry can produce all types of dished ends heads. They can be manufactured from a number of steel types including pressure vessel and boiler quality, chrome moly and stainless steel. The company also offers 2:1 semi ellipsodial, hemispherical petals, torispherical ends as well as conical knuckled sections.

Haipei industry company is a leading producer of various types of dished heads, cones, and other special pressed products in different materials grades like Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations.

Our Services

We offer our products in the following materials:

Carbon Steel: SA36, SA516-70, SA387 Grade 5 Class 2 (Forming Only), SA285 Grade C (Forming Only)

Stainless Steel: SA240T304/304L, SA240T316/316L, SA240T304H (Forming Only), SA240T904/904L (Forming Only)

Copper: O-Temper Material (Forming Only)

Aluminum: O-Temper Material (Forming Only)

Quality assurance
Quality is the most important aspect of strength.We will make the material from the material to the end of the monitoring, making sure that each part can be of high quality according to the regulations.Each program will be monitored to ensure any errors in the manufacturing process.
Competitive price guarantee
With years of experience, we can offer our customers the most competitive prices.At the same time, as a powerful factory, we can offer customers more favorable prices than other factories.
Delivery time guarantee
We will strictly control the manufacturing schedule to ensure punctual delivery.It can satisfy the customer's time schedule and ensure the continuous production of customers.

Packaging & Shipping

Hot Press Elliptical Dished Ellipsoidal Tank Heads

1. Iron Frame2. Wooden Box3. Iron pallet4.Wooden pallet.5.Professional fixation6. Curstomed requirment

FAQ

Q: What’s the information should I provide when inquiry?

A: Thanks for your question. If you have drawings, we will be entirely in accordance with production drawings . If you do not have the drawing, you can tell me the product data. There are several important data, such as material, type of head( We have elliptical head, hemispherical head, dished head, flat head, etc. ),diameter, thickness, special tolerances or requirements. We can do the drawings according to your requirements, and you confirm that the final product drawings.

Q: what are surface treatment of the product?

A:Thanks for your question. For carbon steel products, we sandblasting descaling product surface. For stainless steel products, we use acid to remove surface oil and impurities.

Q: How do you ensure the quality of products?

A: Thanks for your question.Our production staff is trained through national quality department, and obtain the corresponding certificate, with years of production and design experience. Weld must undergo X-ray inspection to ensure that no defects.

Q: Can you help us matching related products?

A: Thanks for your question. Our company also is surrounded by a lot of ancillary businesses, such as flanges, boiler, oil refining equipment, etc. We can help you matching the highest quality products with the lowest prices .
